SWL 4038
Need for a compact and versatile skid-steer loader with good lift capacity and plenty of power?
The Sunward SWL 4038 skid steer loader is highly versatile and compact enough to be easily maneuverable in small spaces. Despite its compact size, you will be impressed by the great breakout force and huge lift capacity. The powerful Kubota engine offers performance, exceptional reliability, long service life and complies with the European Union’s Stage V emission requirements.
| Rated operating capacity | 1 300 kg |
|---|---|
| Tipping load | 2 600 kg |
| Rated power output | 54.6 kW |
| Operating weight | 3 700 kg |
| Breakout force curl | 3 450 kg |
SUNWARD SWL 4038
Need for a compact and versatile skid-steer loader with good lift capacity and plenty of power?
The Sunward SWL 4038 skid steer loader is highly versatile and compact enough to be easily maneuverable in small spaces. Despite its compact size, you will be impressed by the great breakout force and huge lift capacity. The powerful Kubota engine offers performance, exceptional reliability, long service life and complies with the European Union’s Stage V emission requirements.
DIMENSIONS & WEIGHT
| Operating weight | 3 700 kg |
| Length without bucket | 2 984 mm |
| Length with standard bucket | 3 735 mm |
| Width without bucket | 2 015 mm |
| Height to top of ROPS | 2 068 mm |
| Ground clearance | 237 mm |
| Turning radius from center (standard bucket) | 2 254 mm |
ENGINE
| Model | Kubota V3307-CR-TE5B |
| Emission rating | EU Stage V |
| Rated power output | 54.6 kW |
PERFORMANCE
| Rated operating capacity | 1 300 kg |
| Tipping load | 2 600 kg |
| Breakout force curl | 3 450 kg |
| Breakout force lift | 2 600 kg |
| Travel speed | 12~18 km/h |
BUILT FOR MULTITASKING
The Sunward SWL 4038 skid steer loader has been built with versatility and compactness in mind, to be easily maneuverable in small spaces.
A skid-steer versatility starts with how well it is designed for transportation. The SWL 4038 does more than simply align with the EU’s transportation regulations – truly compact (1 812 mm width) and lightweight (3 650 kg), its small frame allows easy, safe, and secure transport behind a pickup truck.
The SWL 4038 can be easily fitted with a wide range of attachments to answer a variety of applications, with perfect control of all functions thanks to the joysticks and double-accelerator control (manual or foot pedal).
RELIABLE PERFORMANCE
Despite its compact size, the SWL 4038 has impressive breakout force, huge lift capacity, and fast cycle times.
The powerful Kubota V3307 engine delivers a power of 54.6 kW (@2 600 rpm) and offers exceptional reliability even in severe, high load conditions, long service life and complies with the European Union’s Stage V emission requirements.
COMFORT AS STANDARD
The comfort of the Sunward SWL 4038 starts with easy cab access. Once seated, the SWL 4038 offers a spacious cab, air conditioning, a comfortable seat, and ergonomic controls for maximum operating comfort.
Operators will be also impressed by the excellent all-around visibility. It is a real pleasure to operate a Sunward skid-steer.
SERVICE MADE EASY
Because we care about your operative costs, maintenance and service have been made easy. Daily preventive maintenance is very simple since service checkpoints and cooling system components are accessible at ground level from the rear door. When it comes to service, major components are also easily and quickly accessible by tilting the ROPS/FOPS cab.
SAFETY IS NOT AN OPTION
Safety is and will always be a priority for Sunward. The SWL 4038 has been designed for operator safety.
Thus, the ROPS/FOPS cab and rear window exit coupled with the excellent visibility and great stability of the machine guarantee maximum safety.
A seat switch and armbar switch also prevent the machine from being started without an operator present.
In terms of systems, the SWL 4038 skid steer has been equipped with an emergency descent function, so that the boom can safely conduct the emergency descent n the event of an unexpected engine shut down.
